Comfort: temperature / humidity
KARE+

Comfort: temperature / humidity

Optimize the comfort of occupants and the energy consumption of a building

Highlights of the IoT sensor

  • Additional functions: alert button, dry contact input
  • A design for a product adaptable to any type of environment
  • Local and remote configuration
  • Data logging to optimize the number of mailings
  • Redundancy
  • Time stamping of IoT data (LoraWAN®)
  • Network test at start-up (LoraWAN®)
  • Battery-powered stand-alone product
  • Compatible with KARE and KARE+ services
  • Available in NB-IoT / LTE-M1 version

Example of use case with the comfort sensor

FEATURES OF THE COMFORT SENSOR

Description

What actions are performed by the temperature and humidity sensor?

Alert

Trigger an alarm if:

  • Exceeded threshold(s)
  • Press on alert button
  • Event on the dry contact input

measure

Monitor:

  • Temperature
  • Humidity level



Count the number of events on the alert button or the dry contact input

What are the technical characteristics of the connected sensor?

Features

  • 1 digital input
  • 1 connected button
  • Periodic and / or event mode
  • Configurable life frame
  • Timestamp
  • Network test at startup
  • Personalisation of the joint phase
  • Redundancy
  • Alarm repetition
  • Local and remote configuration
  • Product error alert, configuration error, low battery
  • Dimensions: 111 x 61 x 40 mm
  • Weight: 102g
  • Case: IP20 (indoor use)
  • Operating temperature range: -20°C /+60°C
  • Integrated fixing system: wall or laid
  • Interchangeable battery
  • Zone:
    • Sigfox RC1
    • LoRaWAN® EU863-870

Subscription

  • orange-iot-business-service
  • Sigfox-Partner-reseaux-iot

Technologies

  • lora lora alliance iot
  • sigfox iot logo

Decoding

What are the part numbers of the sensor?

  • ARF8275A COMFORT LoRaWAN® EU863-870
  • ARF8275C COMFORT Sigfox RC1
  • ARF8275E COMFORT Wireless M-Bus 868 (Submitted to MOQ)

To go further, all documents and tools related to the COMFORT IoT sensor

Previous versions: to find all the documentation related to previous versions of this product, click here.
