GATEWAY

Locally gather transmitter data via the creation of a network infrastructure

Function : Network infrastructure

Available technologies

Description

Highlights

  • Transmission via GPRS
  • Use indoors or outdoors
  • Range up to 1,000 m in Wireless M-Bus
  • Up to 11 years of autonomy
  • IP67 and IK8 standards

Specifications

Wireless M-Bus Interface

  • RF power: 14 dBm (25mW)
  • RF sensitivity: Up to -117 dBm
  • Range: up to 1,000 m

GPRS Interface

  • GSM/DCS GPRS Module
  • Sensitivity: -106 dBm @850/900 MHz
  • E-GSM850/900/1800/1900 MHz (ETSI GSM)
  • GPRS class B Class 10
  • Internal IMEI

Consumption & needs

  • Power supply: Self-powered
  • Lifespan: Up to 11 years

General information

  • Operating temperature range: -40°C to +85°C
  • Dimensions: 138 x 80 x 58.5 mm
  • Box: IP67 & IK8
  • Weight: 485 g
  • Standards: EN 300-220, EN 301-489, EN 60950, EN 13757-4:2005

Reference

  • ARF8011BA  – AMR GATEWAY SELF-POWERED / EXT.ANTENNA

Product uses

Gather data from transmitters

Disseminate data on a remote server
