Delta P: air pressure delta

Delta P: air pressure delta

LoRaWAN / Sigfox sensor

Monitor the operation of a ventilation box, air handling unit or building air system

The Adeunis IoT sensor DELTA P is a ready-to-use radio transmitter that measures a pressure delta between the inside of a ventilation box and atmospheric pressure or a pressure delta on either side of an element (e.g. filter).

The product meets users’ needs who want to monitor a ventilation system remotely.

The product also contains 2 digital inputs/outputs for coupling with newer systems with dry contact outputs and 1 Analog input 0-10 V for coupling with a 0-10 V sensor (current clamp for example).

Highlights of the IoT sensor

Pressure difference: relative to the atmospheric pressure or between two different zones
2 digital inputs / outputs: for connecting to a PLC for tracing alerts or operating states
1 analogue input 0-10V: for connecting to a sensor
Available in: Smart Delta P version

SERVICES RELATED TO THE PRODUCT

FEATURES OF THE DELTA P IoT SENSOR

What actions are carried out by the connected sensor?

Measure

Measure a delta pressure:

Between the atmospheric pressure and the inside of the ventilation box
On both sides of an element (e.g.: filter)

Collect data of a 0-10V sensor

e.g. ammeter clamp for distinguishing a power failure

Alert

On exceeding threshold(s)

Pressure difference or through 0-10V input

On digital input events

e.g.: indication of a machine fault

act

Controlling the AON outputs

Description of the IoT temperature and humidity sensor

What are the technical characteristics of the connected sensor?

Features

Periodic or event mode
Operating temperature range: -20°C /+70°C
Delta pressure: -500/+500Pa
Accuracy: +/- 25Pa
Casing: IP68
Dimensions: 200 x 63.5 x 34 mm
Replaceable battery
Integrated fastening system: DIN rail, tube, wall, collar

Decoding

Datasheet

Datasheet_ADEUNIS_DELTA-P

Where does the sensor operate?

LoRaWAN US902-928

What is the sensor part number?

ARF8283AA DELTA P LoRaWAN® EU863-870

What is the expected battery life of the sensor ?

Under the following conditions: For one frame every 2 hours (12 frames per day) and polling every 10 minutes:

LoRaWAN SF12 or SF7: > 10 years

Certifications:

Directive 2014/53/UE (RED)

For further information, all the useful documents and tools relating to the DELTA P IoT sensor:

User Guide DELTA P LoRaWAN EU863-870

Technical Reference Manual DELTA P

Installation Guide LoRaWAN / Sigfox IP67-IP68

Previous versions: to find all the documentation related to previous versions of this product, click here.

Where does the sensor operate?

Sigfox RC2

What is the sensor part number?

ARF8283CA DELTA P Sigfox RC1

What is the expected battery life of the sensor ?

Under the following conditions: For one frame every 2 hours (12 frames per day) and polling every 30 minutes: 4.1 years

Certifications:

Directive 2014/53/UE (RED)

For further information, all the useful documents and tools relating to the DELTA P IoT sensor:

User Guide DELTA P Sigfox RC1

Technical Reference Manual DELTA P

Installation Guide LoRaWAN / Sigfox IP67-IP68

Previous versions: to find all the documentation related to previous versions of this product, click here.
