BREATH: Indoor Air Quality

BREATH: Indoor Air Quality

Optimising comfort and ensuring the health of occupants

HIGHLIGHTS OF THE IOT SENSOR

  • Multiple functions: PM1, PM2.5, PM10 and VOCT, alert button, dry contact input
  • Daily 24-hour summary log.
  • Information to users: luminous indicator on the box
  • Data sending mode: periodic and/or on events
  • Optimisation of autonomy: historisation
  • Data accessibility: redundancy
  • Network quality test at start-up (LoRaWAN)
  • Class C LoRaWAN
  • Error / fault management: configuration error, hardware fault on the fine particle sensor
  • Local and remote configuration
  • Compatible with KARE and KARE+

EXAMPLE OF USE CASE WITH THE BREATH SENSOR

FEATURES OF THE BREATH SENSOR

Description

What actions are performed by the IoT CO2 sensor?

Measure

Monitor periodically:

  • the level of fine particles
  • the level of TVOCs

Counting the number of events:

  • on the alarm button or the dry contact input

Alert

And/or trigger an alarm if:

  • high or low threshold(s) exceeded
  • press the alert button
  • event on the dry contact input

What are the technical characteristics of the connected sensor?

Features

Mechanical characteristics

  • Weight: 107.5
  • Dimensions: 111 x 61 x 40 mm
  • Housing: IP20, Bayblend® FR3010 (PC/ABS) plastic, white
  • Mounting system: wall or floor

Operating conditions

  • Temperature: 0°C /+50°C
  • Humidity: 0 à 85% RH (non-condensing)

Alimentation

  • External power supply included

Configuration

  • Locally: IoT Configurator
  • Remotely: downlink via the network or via the KARE platform
  • By the air: KARE+ compatible
  • Security: PIN/PUK protection

Technical features

  • Data sending mode: periodic and/or on events
  • Optimisation of autonomy: historisation
  • Data accessibility: redundancy
  • Daily 24-hour summary screen
  • Error / fault management: configuration error, fine particle sensor
    hardware fault
  • Network quality test at start-up (LoRaWAN)
  • Class C LoRaWAN

Radio

  • Area:
    • Sigfox: RC1
    • LoRaWAN®: EU863-870

Regulations and certifications

  • Directive 2014/53/UE (RED)

Retrouvez l’ensemble des caractéristiques techniques dans la datasheet de BREATH

Subscription

  • orange-iot-business-service
  • Sigfox-Partner-reseaux-iot

Technology

  • lora lora alliance iot
  • sigfox iot logo

Decoding

What are the part numbers of the sensor?

  • ARF8377AA BREATH LoRaWAN® EU863-870
  • ARF8377CA BREATH CO2 Sigfox RC1
